The World’s Smallest, Lightest, and Quietest 20,000*1 lm Projector
PT-MZ11KL
Key features
World’s Smallest, Lightest, and Quietest 11,000 lm LCD Projector |
Long-Life Energy-Saving Design Minimizes Problems |
Delivering up to 20,000 lm on AC 100–240 V, a World First |
The World’s Smallest, Lightest, and Quietest LCD Projector with 11,000 lm
The PT-MZ20KL Series is Lightweight, Compact, and Capable of High-Brightness Projection Series suitable for several occurances.
PROJECTOR TYPE | PT-MZ20KL SERIES | |||
---|---|---|---|---|
MODELS | PT-MZ20KL | PT-MZ17KL | PT-MZ14KL | PT-MZ11KL |
RESOLUTION | WUXGA (1920 x 1200 pixels, 16:10) | WUXGA (1920 x 1200 pixels, 16:10) | WUXGA (1920 x 1200 pixels, 16:10) | WUXGA (1920 x 1200 pixels, 16:10) |
BRIGHTNESS | 20 000 lm | 16 500 lm | 14 000 lm | 11 000 lm |
Weight | Approx. 23.0 kg | Approx. 22.5 kg | Approx. 22.5 kg | Approx. 22.5 kg |
World’s Quietest Operation Allows Viewers to Concentrate on Your Presentation
PT-MZ20KL Series achieves the world’s quietest1 operation at 42 dB. Not only does it keep participants focused, it also contributes to an improved sound environment for applications such as hybrid conferences. When a quieter environment is required, noise level can be further reduced to
36 dB by setting the projector to QUIET Mode. This helps create an environment where all viewers can concentrate on the presentation.
1 As of March 2023, based on LCD laser projectors with 20,000 lm brightness and above according to internal research.
Pure White Generator Delivers High Brightness and Rich Color
Pure White Generator, developed by Panasonic Connect, contributes to rich color reproduction at high brightness of 11,000 lm. Efficient light collection uses a multi-reflection system to minimize loss of light-source energy noticeable with conventional systems. It achieves an optimal color balance without sacrificing brightness for realistic and accurate color expression.
Dynamic Contrast NX Realizes a New Dimension of Light and Dark Control
Dynamic Contrast NX, a further evolution of Dynamic Contrast, uses a newly developed video-scene analysis circuit to recognize differences in brightness and darkness more precisely than before.
Product gallery
Specifications table
Feature | Specification |
---|---|
Projector type | LCD projector |
LCD Panel | Panel Size | 25.4 mm (1.0 in) diagonal (16:10 aspect ratio) |
LCD Panel | Display System | Transparent LCD panel (x 3, R/G/B) |
LCD Panel | Drive Method | Active matrix method |
LCD Panel | Pixels | 2,304,000 (1920 x 1200 pixels) |
Light Source | Laser diode |
Light Output*1 *2 | 11,000 lm |
Accessories & Software
Lenses for LCD Projectors > 10.000 lumen
ET-EMT800
4.14-7.40:1 Throw Ratio Zoom lens for PT-MZ16KL/MZ13KL/MZ10KL
Lenses for LCD Projectors > 10.000 lumen
ET-EMT700
2.10-4.14:1 Throw Ratio Zoom lens for PT-MZ16KL/MZ13KL/MZ10KL
Lenses for LCD Projectors > 10.000 lumen
ET-EMW200
0.480-0.550:1 Throw Ratio Zoom lens for PT-MZ16KL/MZ13KL/MZ10KL
Lenses for LCD Projectors > 10.000 lumen
ET-EMU100
Throw Ratio 0.330 – 0.353:1 (Aspect 16:10)0.329 – 0.353:1 (Aspect 16:9)0.396 – 0.425:1 (Aspect 4:3)
Showing 4 of 11
Filters
ET-RFM100
The Replacement Filter Unit (3LCD) is designed for compatibility with MZ Series projectors.
Showing 1 of 1
