LCD Projector

PT-CMZ50

Veja especificações completas Compartilhar Página

Key features of PT-CMZ50

Principais Características

Project Large Images in Rooms with Limited Space

Simplified Installation, Setup, and Adjustment

Stress-free Daily Operation

Laser Projector Delivers Big Pictures from Ultra-Short Distances with Minimal Shadowing, Easy Installation, and Convenient Adjustment

	PT-CMZ50 Projetor LCD
Brilho	5.200 lm
Resolução	WUXGA (1920 x 1200 pixels)
Relação de lançamento	0.235:1
Tecnologia	LCD
Peso	Aprox. 9,5 kg

Grandes Imagens com Menos Sombras

Compartilhe imagens grandes de 80 a 120 polegadas em salas de qualquer tamanho, de pequenas salas de reunião a salas de aula híbridas, onde o espaço de instalação no teto é limitado. O design compacto ultracurto pode fornecer uma imagem de 80 polegadas a uma distância de cerca de 1 cm (1/3 pol.) ^1º. Como a lente está à frente do apresentador, o sombreamento e o deslumbramento são reduzidos para que todos possam se comunicar confortavelmente. A imagem grande e a resolução detalhada do WUXGA tornam-no ideal para a exibição de texto pequeno.

1 Valor é a distância do corpo do projetor até a parede.

Design elegante harmoniza com o seu espaço

O deslocamento mínimo da tela do projetor o torna uma escolha prática para salas com tetos baixos, onde ele se instala quase nivelado à parede. Disponível em preto ou branco, sua carroceria integrada não tem saliências para estragar um estilo limpo e elegante que harmoniza com qualquer design de interiores. Instalado em um escritório, sala de aula ou museu, este projetor discreto desaparece da consciência do grupo para que a atenção permaneça focada na apresentação.

Design ultra-silencioso para espaços híbridos

A fonte de luz resistente ao calor do CMZ50 reduz significativamente o ruído do escapamento e as distrações indesejadas quando as pessoas estão sentadas perto do projetor. A corrida silenciosa também melhora a audibilidade das conversas durante aulas e reuniões híbridas, reduzindo o ruído de fundo. No Modo Silencioso, seu ruído operacional é de apenas 25 dB¹, aproximadamente o mesmo volume aparente das folhas farfalharem. Na verdade, com um volume percebido que é menos de um terço² do de um projetor baseado em lâmpada comparável, o CMZ50 mantém todos alertas e focados na apresentação.

1 34 dB no modo NORMAL/ECO.

2 Baseado na comparação entre PT-CMZ50 (25 dB) e PT-TW381R (30 dB) no Modo SILENCIOSO. O ouvido humano percebe mudanças na intensidade sonora em uma escala logarítmica. A diferença percebida no volume sonoro entre os dois produtos foi calculada por meio da seguinte fórmula: Diferença percebida = 10^ [(dB1 - dB2) / 10].

Galeria de produtos

Specifications of PT-CMZ50

Tabela de especificações

Projector type	LCD projector
Display method	Transparent LCD panel (x 3, R/G/B)
Display Device -> Panel size	16.3 mm (0.64 in) diagonal (16:10 aspect ratio)
Display Device -> Drive method	Active matrix method
Display Device -> Number of pixels	2,304,000 (1920 x 1200 pixels)
Light source	Laser diodes
Light output^*1	5,200 lm
Light output (ANSI)	5,200 lm

Veja especificações completas

Full specifications

Download specifications

Projector type	LCD projector
Display method	Transparent LCD panel (x 3, R/G/B)
Display Device -> Panel size	16.3 mm (0.64 in) diagonal (16:10 aspect ratio)
Display Device -> Drive method	Active matrix method
Display Device -> Number of pixels	2,304,000 (1920 x 1200 pixels)
Light source	Laser diodes
Light output^*1	5,200 lm
Light output (ANSI)	5,200 lm
Time until light output declines to 50 % -> NORMAL^*3	20,000 hours [NORMAL]
Time until light output declines to 50 % -> ECO^*6	24,000 hours [ECO]
Time until light output declines to 50 % -> QUIET^*4	20,000 hours [QUIET]
Resolution	WUXGA (1920 x 1200 pixels)
Contrast Ratio (typ.)^*1	3,000,000:1 (Full On/Full Off) (When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1].)
Screen size (diagonal)	2.03–3.05 m (80–120 in) (16:10 aspect ratio)
Center-to-corner zone ratio^*1	85%
Lens	Fixed zoom, powered focus lens, F = 1.7, f = 2.81 mm, throw ratio: 0.235:1 (16:10 aspect ratio) (Projection distance: 1 cm [1/3 in] for 80-inch image)
Digital Zoom Extender	Throw ratio 0.235–0.288:1*5 (16:10 aspect ratio) (Corresponding value)
Keystone correction range	Vertical: ±3 °, Horizontal: ±3 °
Installation	Ceiling/floor, front/rear, free 360-degree installation
Terminals -> HDMI^™ IN	HDMI^TM 19-pin x 2 (Compatible with HDCP 1.4, Deep Color, 4K/30p6 signal input), CEC supported7
Terminals -> HDMI^™ OUT	HDMI^TM 19-pin x 1 (Compatible with HDCP 1.4, Deep Color, 4K/30p*6 signal output)
Terminals -> COMPUTER IN（D-SUB 15pin）	D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR)
Terminals -> AUDIO IN(M3 Stereo Mini Jack)	M3 stereo mini-jack x 1
Terminals -> AUDIO OUT(M3 Stereo Mini Jack)	M3 stereo mini-jack x 1
Terminals -> SERIAL IN	D-sub 9-pin (female) x 1 for computer control (RS-232C compliant)
Terminals -> DIGITAL LINK IN / LAN	RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT^TM compliant), 100Base-TX (Compatible with PJLink^TM [Class 2], HDCP, Deep Color, 4K/30p*6 signal input)
Terminals -> LAN	RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLink^TM [Class 2]
Terminals -> USB TYPE A	USB connector (Type A) x 1 for Memory Viewer function, optional AJ-WM50 Series Wireless Module, power supply (DC 5 V, maximum 2 A)
Protocol versions	IPv4, IPv6*8
Power supply	AC 100–240 V, 50/60 Hz
Maximum power consumption	325 W (3.4–1.4 A) (330 VA) (Power consumption is 310 W at AC 200–240 V)
On-mode power consumption(Operating mode) -> Normal	[NORMAL]290 W (AC 100–120 V), 280 W (AC 200–240 V)
On-mode power consumption(Operating mode) -> Eco^*8	[ECO]215 W (AC 100–120 V), 205 W (AC 200–240 V)
On-mode power consumption(Operating mode) -> Quiet	[QUIET]210 W (AC 100–120 V), 200 W (AC 200–240 V)
Built-in speaker	10 W monaural
Cabinet materials	Molded plastic
Filter	Included
Estimated filter maintenance cycle	Approx. 20,000 hours
Operation noise -> Normal^*1	34 dB [NORMAL]
Operation noise -> Eco^*3	34 dB [ECO]
Operation noise -> Quiet^*1	25 dB [QUIET]
Dimensions (W x H x D)	495 mm x 160 mm x 421 mm (19 1/2˝ x 6 19/64˝ x 16 37/64˝) (excluding feet and protrusions), 495 mm x 176 mm x 421 mm (19 1/2˝ x 6 15/16˝ x 16 37/64˝) (with feet at shortest position)
Dimensions (W x H x D) -> Width (not including protruding parts)	495 mm (19 1/2˝)
Dimensions -> Width (including protruding parts)	495 mm (19 1/2˝)
Dimensions -> Height (not including protruding parts)	160 mm (6 19/64˝)
Dimensions -> Height (including protruding parts)	176 mm (6 15/16˝)
Dimensions -> Depth (not including protruding parts)	421 mm (16 37/64˝)
Dimensions -> Depth (including lens)	421 mm (16 37/64˝)
Weight^*7	Approx. 9.5 kg (20.9 lbs)
Operating environment -> Operating temperature^8^9	0–45 °C (32–113 °F)
Operating Environment -> Operating humidity (No condensation)	20–80 % (no condensation)
Applicable software	Multi Monitoring & Control Software, Logo Transfer Software, Projector Network Setup Software, Presenter Light Software for Windows®13, Wireless Projector App for iOS/Android^TM14
Control function via LAN	PJLink^TM [Class 2], Crestron Connected^TM, AMX Device Discovery
Footnote Description	When [PICTURE MODE] is set to [DYNAMIC], [LIGHT POWER] is set to [NORMAL], and [SYSTEM DAYLIGHT VIEW] is set to [OFF]. Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped. Measurement, measuring conditions, and method of notation all comply with American National Standards Institute standards. Value is the average of all products when shipped. Around this time, light output will have decreased to approximately 50 % of its original level ([PICTURE MODE]: [DYNAMIC], [DYNAMIC CONTRAST] set to [2], temperature 30 °C (86 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of particulate matter). Estimated time until light output declines to 50 % varies depending on environment. Resolution decreases when using Digital Zoom Extender. Some screen-correction functions are not available when using this function, and range of corner adjustment is limited. When Digital Zoom Extender is set to 80 %. Supports signals up to 4K/30p. A signal with different resolution is converted to the number of display dots (1920 x 1200 dots). Depending on the connected CEC command-compatible device, the link control may not operate normally. Main version of the firmware must be 2.00 or higher. Optional wireless module AJ-WM50 does not support IPv6. Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. On-mode power consumption measured at 25 °C (77 °F) operating temperature at an altitude of 700 m (2,297 ft). Filter cleaning cycle varies depending on environment. Filter can be washed and reused up to two times. Filter cleaning cycle: 20,000 hours (under dust conditions of 0.08 mg/m3), 10,000 hours (under dust conditions of 0.15 mg/m3). Average value. May differ depending on the actual unit. Light output is limited at operating temperatures higher than 30 °C (86 °F), and projectors cannot be operated at altitudes higher than 2,700 m (8,858 ft) above sea level. When optional AJ-WM50 Series wireless module is attached, operating temperature range becomes 0–40 °C (32–104 °F). When using Presenter Light Software, images are projected with 1280 x 800 dots or 1024 x 768 dots onto the screen. Also, your PC display resolution may be forcibly changed, and audio playback disrupted or become noisy, while images and sound are being transmitted. When using the Wireless Projector app, display resolution differs depending on your iOS/Android™ device and the display device. The maximum supported display resolution is WXGA (1280 x 800).
